Before

After

1. On the [Model] tab, go to and click ▼ at the side of [Sheet Body] .

   Then click [Circle] on the submenu.

2. Designate the startpoint.

   In the parameter input dialog box, enter Startpoint (X:25, Y:71, Z:9) and click .



3. Enter Radius: 10 and click .


4. Click in the parameter input dialog box and exit.


5. On the [Model] tab, go to



   and click ▼ at the side of [Extrude] .

   Then click [Extrude with Taper] on the submenu.


6. Highlight the circle created at 4 and click to select.




7. Click in the parameter input dialog box.

8. Enter the Extrusion vector (X:0, Y:0, Z:-1) in the parameter input dialog box and click .


9. Reference point (X:25, Y:71.0..., Z:8) is the gravity center. Click .


10. Enter the Scale factor: 0.4 and click .


The truncated cone is now ready.
